MPM4710
You have a basic account.A myMPS+ account is needed.
Upgrade to myMPS+Session textval
Session Titefor popup
Description
The MPM4710 is a high-efficiency buck-boost power module with an integrated inductor. The device can operate from a 1.2V to 5.5V input voltage (VIN) range to provide between 1.5V and 5.5V of output voltage (VOUT). It can also operate at input voltages above, below, or equal to VOUT.
Current-mode control with pulse-width modulation (PWM) frequency improves stability and transient response. For low-noise applications, pull the MODE/SYNC pin high to make the part operate in fixed-frequency PWM mode under all load conditions.
The 2MHz fixed switching frequency (fSW) allows for small external components, while internal compensation and soft start (SS) minimize the external component count. The MPM4710 is available in a small ECLGA-14 (2.5mmx2.5mmx1.2mm) package.
-
Show more
Show less
Features & Benefits
- 1.8V Minimum Start-Up Input Voltage (VIN)
- 1.2V to 5.5V Operating VIN Range
- 1.5V to 5.5V Output Voltage (VOUT) Range
- 1A Typical Output Current (IOUT), 2A Max IOUT
- 2MHz Fixed/External Synchronous Switching Frequency (fSW)
- Selectable Pulse-Skip Mode (PSM) or Pulse-Width Modulation (PWM) Mode
- 25μA Quiescent Current (IQ)
- Shutdown Load Disconnect
- Internal Soft Start (SS) and Compensation
- Power Good (PG) Indication
- Short-Circuit Protection (SCP) with Hiccup Mode
- Over-Temperature Protection (OTP)
- Available in an ECLGA-14 (2.5mmx2.5mmx1.2mm) Package

Active Part Numbers:
MPM4710GPA-Z MPM4710GPA-P
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
