MP1469

4.7V to 16V, 500kHz, 1.5A Sync Buck with TSOT23-6 Package

Newer version available

Datasheet

Overview
Design Resources
Technical Forum
Quality

Vin (Max) 14V to 19V
MP1469

MP1469

4.7V to 16V, 500kHz, 1.5A Sync Buck with TSOT23-6 Package

Newer version available

Datasheet

Description

The MP1469 is a high-frequency, synchronous, rectified, step-down, switch-mode converter with internal power MOSFETs. It offers a very compact solution to achieve a 1.5A continuous output current over a wide input supply range, with excellent load and line regulation. The MP1469 has synchronous-mode operation for higher efficiency over the output current-load range. Current-mode operation provides fast transient response and eases loop stabilization. Protection features include over-current protection and thermal shutdown. The MP1469 requires a minimal number of readily-available, standard, external components and is available in a space-saving 6-pin TSOT23 package.

Features & Benefits

Wide 4.7V-to-16V Operating Input Range
255mΩ/160mΩ Low-RDS(ON) Internal Power MOSFETs
Proprietary Switching-Loss–Reduction Technique
High-Efficiency Synchronous-Mode Operation
Fixed 500kHz Switching Frequency
AAM Power-Save Mode for High Efficiency at Light Load
Internal Soft-Start
Over-Current Protection and Hiccup
Thermal Shutdown
Output Adjustable from 0.8V
Available in a 6-pin TSOT-23 package

Active Part Numbers:

MP1469GJ-P MP1469GJ-P MP1469GJ-Z

Recommended Inductors

Molded Inductor 6.8µH

Molded Inductor 6.8µH

Semi-Shielded Inductor 6.8µH

Show more

Show more

Inductor Selector Tool

*Based on Nominal Values
