Automotive Grade 500mA Linear Regulator

Talk to an Engineer or get a Quote

Product Description

The MPQ8904 is a low-current, low-dropout, linear regulator that operates on a single 2.5V-to-6.5V input supply. An external resistor controls the output voltage. The MPQ8904 can supply up to 500mA of load current. The enable pin (EN) allows the part to enter a low-current shutdown mode (EN=0). The MPQ8904 features thermal overload and current limit protection. It is available in an 8-pin QFN (2×3mm) package.

Product Features

  • Power-Good Open Collector Output
  • Guaranteed Industrial/Automotive Temp. Range Limits
  • Operates from a 2.5V-to-6.5V Input
  • Low 300mV Dropout at 500mA Output
  • Stable with Very Small Ceramic Capacitors
  • 2.5% Feedback Reference
  • Adjustable Output Voltage from 0.5V to 5V
  • Better than 0.001%/mA Load Regulation
  • Stable with Low-ESR Output Capacitor
  • Low 140µA Ground Current
  • Internal Thermal Protection
  • Current Limit Protection
  • 7µA Typical Quiescent Current at Shutdown
  • Available in AEC-Q100 Qualified Grade 1


  • Vdropout (mV)300 (IO:500mA)
  • Special FeaturesCurrent Limiting, Power Good
  • PackageQFN-8 (2x3)
  • GradeAutomotive
  • Vout (min) (V)0.5
  • Vout (max) (V)5
  • PSRR @ 1kHz (dB)78
  • Iq (typ) (µA)140
  • Iout (mA)500
  • Vin (max) (V)6.5
  • Vin (min) (V)2.5
Quality Policy, Certificates & Reliability Reports
All MPS parts are lead-free, halogen-free and adhere to the RoHS directive. See Environmental section for details.
