MP2562
4.5V to 50V, 1A, Up to 4MHz Switching Frequency Step-Down Converter with Output Adj From 0.8V to 47V
アクティブ部品番号
MP2562DQ-LF-P MP2562DQ-LF-Z MP2562DS-LF-P MP2562DS-LF-Z
P&Zの意味
Evaluation Tools

EV2562DS-00A Evaluation Kit 1A, 50V, 4MHz Step-Down Converter Evaluation Board
The EV2562DS-00A is an evaluation board for the MP2562, a high frequency step-down regulator with an integrated power MOSFET.
The MP2562 integrates a 460m? MOSFET that provides 1A load current over a wide operating input voltage of 4.5V to 50V.
Current mode control provides fast transient response and reliable over current protection. An internal soft-start prevents inrush current at turn-on.
The EV2562DS-00A is a fully assembled and tested PCB. It generates a +3.3V output voltage at load current up to 1A from an 8V to 50V input range. Switching frequency is set at 500KHz.
推奨インダクター
セミシールドインダクタ 1.5µH
