OrderMPM3606A
21V Input, 0.6A Module Synchronous Step-down Converter with Integrated Inductor and PG pin
Active Part Numbers:
MPM3606AGQV-P MPM3606AGQV-Z
Meaning of P & Z
Evaluation Tools
EVM3606A-QV-00A Evaluation Kit 21V/0.6A Module Converter With Integrated Inductor Evaluation Board
The EVM3606A-QV-00A is an evaluation board for MPM3606A, a synchronous rectified, step-down module converter with built-in power MOSFETs, inductor and two capacitors.
The evaluation board can deliver a 0.6A continuous output current with excellent load and line regulation over a wide input supply range.
Current-mode operation provides fast transient
response and eases loop stabilization.
Full protection features include over-current protection and thermal shut down.
The MPM3606A is available in a space-saving QFN20 (3mm x5mmx1.6mm) package.
