VU45P, VU47P UltraScale+ Extended Portfolio Smallest Size Power Management Reference Design
REFERENCE DESIGN
For more information on reference designs
Response within 2 business days
AMD Xilinx part numbers:
- XCVU45P
- XCVU47P
MPS Products Used
| Part Number | Quantity | Description |
| MPM3695-100-0001 |
1 for 80A; 2 for 150A |
100A, Scalable, and Fully Integrated DC/DC Power Module with a PMBus interface |
| MPM3695-25-0022 | 3 | 16V, 20A, Scalable DC/DC Power Module with PMBus |
| MPM3695-10-0022 | 2 | 16V, 10A, Scalable, Ultra-Thin DC/DC Power Module with PMBus |
| MPM3632C | 1 | 18V Input, 3A Module, Synchronous, Forced CCM, Step-Down Converter with Integrated Inductor |
| MPM3650 | 1 | 1.2MHz Synchronous 2.75 - 17V, 5A Ultra-Thin Power Module |
| MPM3606A | 1 | 21V Input, 0.6A Module Synchronous Step-down Converter with Integrated Inductor and PG pin |
| MP20075 | 1 | 3A, DDR Termination Regulator |
