MPL-AT2010

モールド構造
磁気シールド

コンパクトなデザイン
低可聴ノイズ

ソフトサチュレーション
高温で安定

MPL-ATシリーズは、設計上、高さに制限があるアプリケーションに最適な非常に薄型の製品です。このシリーズは、低DCR / ACRと大電流を処理する機能も提供します。

Inductor Selector Tool

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
*Based on Nominal Values
参照表示列
ステータス
MPS在庫状況
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
MPSafe
MPL
Product URL
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
MPSから購入
0.47
0.68
1.0
1.5
2.2
4.7
+125°C
2.0
1.60
1.0
SMD
Is MPSafe Has MPL Product URL

MPL-AT2010-R47
Low-Profile Molded Inductor 0.47µH
MPSから購入 0.47 27 4.4 5.7 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-r47.html
MPL-AT2010-R68
Low-Profile Molded Inductor 0.68µH
MPSから購入 0.68 41 3.5 4.9 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-r68.html
MPL-AT2010-1R0
Low-Profile Molded Inductor 1.0µH
MPSから購入 1.0 50 3.2 4.2 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-1r0.html
MPL-AT2010-1R5
Low-Profile Molded Inductor 1.5µH
MPSから購入 1.5 97 2.4 3.2 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-1r5.html
MPL-AT2010-2R2
Low-Profile Molded Inductor 2.2µH
MPSから購入 2.2 137 2.2 2.7 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-2r2.html
MPL-AT2010-4R7
Low-Profile Molded Inductor 4.7µH
MPSから購入 4.7 215 1.5 1.9 125°C 2.0 1.60 1.0 SMD 0 0 https://www.monolithicpower.com/jp/mpl-at2010-4r7.html
他の該当製品型番はありません
