MPL-AL5030

Molded Construction
Magnetically Shielded

High Performance
Low ACR/DCR Losses

Soft Saturation
Stable Over High Temperatures

The MPL-AL Series offers Low DCR/ACR and a flat-wire construction, which provides even higher current ratings than round-wire molded inductors.

Inductor Selector Tool

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
*Based on Nominal Values
参照表示列
ステータス
MPS Inventory
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
MPSafe
MPL
Product URL
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
Buy On MPS
0.47
0.56
0.82
1.0
1.2
1.5
1.8
2.2
3.3
4.7
+155°C
5.50
5.30
2.90
SMD
Is MPSafe Has MPL Product URL

MPL-AL5030-3R3
Low-Profile Molded Inductor 3.3µH
Buy On MPS 3.3 21 6.0 10 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-3r3.html
MPL-AL5030-4R7
Low-Profile Molded Inductor 4.7µH
Buy On MPS 4.7 33 5.3 8 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-4r7.html
MPL-AL5030-1R0
Low-Profile Molded Inductor 1.0µH
Buy On MPS 1.0 6.5 11.2 16 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-1r0.html
MPL-AL5030-1R2
Low-Profile Molded Inductor 1.2µH
Buy On MPS 1.2 8.0 10.0 14 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-1r2.html
MPL-AL5030-1R5
Low-Profile Molded Inductor 1.5µH
Buy On MPS 1.5 9.7 9.0 12.5 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-1r5.html
MPL-AL5030-1R8
Low-Profile Molded Inductor 1.8µH
Buy On MPS 1.8 10.5 8.8 12 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-1r8.html
MPL-AL5030-2R2
Low-Profile Molded Inductor 2.2µH
Buy On MPS 2.2 12.3 8.2 11 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-2r2.html
MPL-AL5030-R47
Low-Profile Molded Inductor 0.47µH
Buy On MPS 0.47 3.78 13.6 26.5 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-r47.html
MPL-AL5030-R56
Low-Profile Molded Inductor 0.56µH
Buy On MPS 0.56 3.92 13.2 22 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-r56.html
MPL-AL5030-R82
Low-Profile Molded Inductor 0.82µH
Buy On MPS 0.82 5.0 12.8 18 155°C 5.50 5.30 2.90 SMD 0 0 https://www.monolithicpower.com/jp/mpl-al5030-r82.html
他の該当製品型番はありません
