MP6516

5.4V - 35V, 2.8A, H-Bridge Motor Driver in TSSOP16-EP

Datasheet

概要

The MP6516 is an H-bridge motor driver that operates from a supply voltage up to 35V and delivers a motor current up to 2.8A. Typically, the MP6516 is used to drive a DC brush motor. For the MP6516, control of each half-bridge is independent, using IN1, IEN1, IN2, and EN2 pins.

An internal current-sensing circuit provides an output voltage proportional to the load current. The MP6516 also has cycle-by-cycle current regulation and limiting. These features do not require the use of a low-ohm shunt resistor.

Full protection features include over-current protection (OCP), input over-voltage protection (OVP), under-voltage lockout (UVLO), and thermal shutdown.

The MP6516 is available in a 16-pin TSSOP-EP (5.0mmx6.4mm) with an exposed thermal pad.

機能と利点

Wide 5.4V to 35VInputVoltageRange
2.8APeak Output Current
½-H control, input logic (INx, ENx)
Internal Full H-Bridge Driver
Cycle-by-cycle Current Regulation / Limit
Low On Resistance (HS:250mΩ, LS:250mΩ)
Simple, Versatile Logic Interfaces
3.3V and 5V Compatible Logic Supply
Over-Current Protection (OCP)
Over-Voltage Protection (OVP)
Thermal Shutdown
Under-Voltage Lockout (UVLO)
Fault Indication Output
Available in a Thermally Enhanced Surface-Mounted TSSOP-16 EP Package

アクティブ部品番号

MP6516GF-P MP6516GF-Z

P&Z的含义

Evaluation Tools

EV6516-F-00A Evaluation Kit 2A, 35V, H-Bridge Motor Driver Evaluation Board

The EV6516-F-00A is an evaluation board for the MP6516, an H-bridge motor driver.

It operates from a supply voltage of up to 35V, and can deliver a motor current up to 2A. The input control signals for the MP6516 are applied through the connector on the board.
