Description
The MP86933 is a monolithic, half-bridge driver with built-in, internal power MOSFETs and gate drivers. The MP86933 achieves 12A of continuous output current over a wide input supply range and can operate from 100kHz to 2MHz.
The integration of a driver and MOSFETs results in high efficiency due to an optimal dead time and parasitic inductance reduction.
The MP86933 works with tri-state output controllers and comes with a general-purpose current sense and temperature sense.
The MP86933 is ideal for server and telecom applications where efficiency and small size are a premium. The MP86933 is available in a small FC-TQFN-13 (3mmx3mm) package.
-
Show more
Show less
Features & Benefits
- Wide 4.5V to 16V OperatingInputRange
- Compliant with Intel DrMOS V4.0 Spec
- 12A Output Current
- Accepts Tri-State PWM Signal
- Built-In Switch for Bootstrap
- Current Sense
- Temperature Sense
- Current-Limit Protection
- Over-Temperature Protection (OTP)
- Fault Reporting: Over-Current and Over-Temperature
- Used for Multi-Phase Operation
- Available in a TQFN-13 (3mmx3mm) Package
Active Part Numbers:
MP86933 MP86933GQT-Z
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
