MP5088
5.5V, 15A, Low 2mΩ RDS(ON) E-Fuse with Inrush Current Control and Current Monitoring
Session textval
Session Titefor popup
Description
The MP5088 is an e-fuse that supports a continuous current up to 15A and covers a 2.7V to 5.5V input voltage (VIN) range. With inrush current control, current monitoring, and a low 2mΩ on resistance (RDS(ON)) in a tiny package, the MP5088 provides a highly efficient, space-saving solution.
The MP5088 is equipped with a highly accurate current-monitoring function and a configurable current limit. With its soft-start (SS) function, the MP5088 can avoid inrush current during circuit start-up. The MP5088 also provides a configurable soft-start time (tSS), output discharge function, over-current protection (OCP), and thermal shutdown.
The MP5088 is available in a UTQFN-12 (2mmx2mm) package.
-
Show more
Show less
Features & Benefits
- 2.7V to 5.5V Input Voltage (VIN) Range
- Integrated, Low 2mΩ On Resistance (RDS(ON)) MOSFET
- 5µA Shutdown Current
- Configurable Current Limit Up to 15A
- Open-Drain Power Good (PG) Indicator
- Adjustable Start-Up Slew Rate through the SS Pin
- Output Discharge Function
- 500ns Short-Circuit Protection (SCP) Response
- Over-Temperature Protection (OTP)
- Available in a UTQFN-12 (2mmx2mm) Package
Active Part Numbers:
MP5088GGU-Z MP5088GGU-P
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
