MPC22167-130

16V, 130A, Dual-Phase Intelli-Module^TM with Quiet Switcher^TM Technology

Datasheet

Description

The MPC22167-130 is a dual-phase, non-isolated, high-efficiency step-down power module. It integrates driver MOSFETs (DrMOS) and inductors to provide high efficiency and a small footprint, which is ideal for server applications.

The MPC22167-130 has two independent outputs, which can be used separately or in parallel. It can achieve up to 130A (65A/phase) of output current (I_OUTx) across a wide input voltage (V_IN) range.

The MPC22167-130 offers many features to simplify system design. The device works with tri-state pulse-width modulation (PWM) signal controllers, has Accu-Sense^TM current sensing to monitor the inductor current (I_L), and has temperature sensing to report the junction temperature (T_J).

The MPC22167-130 is available in an LGA-72 (9mmx9.9mmx8mm) package.

Features & Benefits

Quiet Switcher^TM Technology (QST) Limits Peak Switching Voltages
Wide 4V to 16V Input Voltage (V_IN) Range
Up to 130A Continuous Output Current (I_OUTx)
Accu-Sense^TM Current Sense (CS)
Temperature Sense
Compatible with Tri-State Pulse-Width Modulation (PWM) Signals
Over-Current Protection (OCP)
Over-Temperature Protection (OTP)
Fault Reporting
Typical Weight: 3.4g
Available in an LGA-72 (9mmx9.9mmx8mm) Package

Active Part Numbers:

MPC22167-130-T

Related Products

EVMPC22167-2891-Split-02A 130A, Two-Phase Intelli-Module^TM with Quiet Switcher^TM Technology Evaluation Board

The EVMPC22167-2891-Split-02A is an evaluation board designed to demonstrate the capabilities of the MPC22167-130, a 130A two-phase Intelli-Module^TM with Quiet Switcher^TM Technology.

The EVMPC22167-2891-Split-02A can deliver up to 130A of load current across a wide operating input voltage (V_IN) range. High efficiency can be achieved across a wide output current (I_OUT) load range.

The EVMPC22167-2891-Split-02A employs one MP2891 and two MPC22167-130 devices. These devices form two power supply rails, which can be run independently.

The EVMPC22167-2891-Split-02A can monitor the MPC22167-130’s V_IN, output voltage (V_OUT), I_OUT, and temperature. Full protection features include integrated, configurable V_IN under-voltage lockout (UVLO) protection, as well as V_OUT over-voltage protection (OVP), under-voltage protection (UVP), over-current limit (OCL), and over-current protection (OCP).
