MPQ86940

MPQ86940

40A Intelli-Phase^TM Solution in a TQFN-21 (4mmx5mm) Package, AEC-Q100 Qualified

Datasheet

Description

The MPQ86940 is a monolithic half-bridge with built-in, internal power MOSFETs and gate drivers. It can achieve up to 40A of continuous output current (I_OUT) across a wide input voltage (V_IN) range. The integrated MOSFETs and drivers achieve high efficiency through an optimized dead time (DT) and reduced parasitic inductance.

The MPQ86940 is compatible with tri-state output controllers. It also includes general-purpose current sensing and temperature sensing. The MPQ86940 is ideal for autonomous driving applications where efficiency and compact size are at a premium.

The MPQ86940 is available in a TQFN-21 (4mmx5mm) package.

Features & Benefits

Wide Operating Input Voltage (V_IN) Range
40A Output Current (I_OUT)
Accepts Tri-State Pulse-Width Modulation (PWM) Signal
Built-In Bootstrap (BST) Switch
Quiet Switcher^TM Technology
Accu-Sense^TM Current Sense
Temperature Sense
Current-Limit Protection and Fault Flag
Over-Temperature Protection (OTP) and Fault Flag
Compatible with Multi-Phase Operation
Available in a TQFN-21 (4mmx5mm) Package
Available in AEC-Q100 Grade 1

Active Part Numbers:

MPQ86940GVTE-AEC1-Z MPQ86940GVTE-AEC1-P
