MP4587

MP4587

80V, 8A, Synchronous, Step-Down DC/DC Converter with Dual-Phase Operation Supported

Description

The MP4587 is a high-efficiency, synchronous step-down converter with integrated high-side and low-side MOSFETs (HS-FET and LS-FET, respectively). It supports up to 8A of continuous output current (I_OUT), with excellent load and line regulation across the wide input voltage (V_IN) supply range.

High power conversion efficiency across a wide load range is achieved through power-save mode (PSM). The MP4587's fixed-frequency constant-on-time (COT) control architecture provides fast transient response and eases loop stabilization.

The MP4587's operating frequency is configurable via the FREQ pin. In addition, the device can be synchronized to an external clock in single-phase applications.

Full protection features include over-current protection (OCP), short-circuit protection (SCP) with hiccup mode, output voltage (V_OUT) over-voltage protection (OVP), and over-temperature protection (OTP).

The MP4587 is available in a QFN-37 (6mmx6mm) package with wettable flanks.

Features & Benefits

5.5V to 80V Input Voltage (V_IN) Range
0.8V to 16V Output Voltage (V_OUT)
Up to 8A Continuous Output Current (I_OUT) and 10A Peak I_OUT
Internal 21mΩ/15mΩ Low On Resistance (R_DS(ON)) MOSFETs
Selectable Power-Save Mode (PSM) or Forced Continuous Conduction Mode (FCCM)
Configurable 100kHz to 600kHz Switching Frequency (f_SW)
External Clock Synchronization for Single-Phase Operation
Fixed-Frequency Constant-On-Time (COT) for Ultra-Fast Transient Response
Supports Auto-Bias from V_OUT for High Efficiency
Lossless and Accurate LS-FET Current Sense with Temperature Compensation
Supports Up to Dual-Phase Paralleled Operation with Phase Shift Control
Accurate Current Balance in Dual-Phase Operation
Power Good (PG) Indication
Configurable Soft Start (SS)
Output Over-Current Protection (OCP), Over-Voltage Protection (OVP), and Thermal Shutdown
Available in a QFN-37 (6mmx6mm) Package with Wettable Flanks
