- MP4588
MP4588
Session textval
Session Titefor popup
Description
The MP4588 is a high-efficiency, synchronous step-down converter with integrated power MOSFETs. It provides 0.8A of output current (IOUT) in a buck topology from an input power supply up to 100V.
The MP4588 features constant-on-time (COT) control, which provides fast transient response and eases loop stabilization.
The MP4588 supports high-efficiency pulse-skip mode (PSM) while operating under light-load conditions. The valley current limit circuits protect against overload and short-circuit conditions.
The MP4588 is available in a QFN-14L (3mmx3mm) package.
-
Show more
Show less
Features & Benefits
- 8V to 100V Input Voltage (VIN) Range
- 1V to 30V Output Voltage (VOUT) Range
- 90% Maximum Operating Duty Cycle
- 580mΩ/260mΩ Internal Power MOSFETs
- Constant-On-Time (COT) Control
- Internal Soft Start (SS) and Loop Compensation
- Over-Current Protection (OCP)
- Short-Circuit Protection (SCP) with Latch-Off Mode
- High-Efficiency Pulse-Skip Mode (PSM) under Light-Load Conditions
- Available in a QFN-14L (3mmx3mm) Package
Active Part Numbers:
MP4588GQ-Z MP4588GQ-P
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
