The EVM3683-7-QN-01A Evaluation Board is designed to demonstrate the capabilities of MPS’ MPM3683-7.The MPM3683-7 is an easy-to-use fully integrated peak10A, continuous 8A step-down DC/DC power module. MPM3683-7 can deliver output current over a wide input supply voltage range with excellent load and line regulation.
The MPM3683-7 uses Constant-On-Time (COT) control to provide fast transient response and ease the loop stabilization.
The operating frequency is set easily to 600 kHz, 800 kHz, or 1000 kHz with the MODE configuration, allowing the MPM3683-7 frequency to remain constant regardless of the input/output voltages.
The MPM3683-7 is available in a space-saving QFN-28 (7mmx7mmx4mm) package.
