MPQ79531FS-AEC1

MPQ79531FS-AEC1

MPSafe^TM, ASIL-B, 3-Channel Voltage Monitor, AEC-Q100 Qualified

Description

The MPQ79531FS-AEC1 is a 3-channel voltage monitor. It is engineered for automotive applications that require voltage rails to be monitored for safety, such as advanced driver-assistance systems (ADAS) and autonomous driving platforms.

Each voltage monitor input has configurable over-voltage (OV) and under-voltage (UV) thresholds. Highly accurate high-frequency (HF) and low-frequency (LF) voltage monitoring can detect when the voltage thresholds are reached.

The MPQ79531FS-AEC1 can record the order in which voltage rails are sequenced, as well as their associated timestamps. The device also provides a sync input/output (I/O) function, which allows multiple devices to be connected together to increase the number of voltage rails that can perform these functions. The device is accessible through an I²C interface.

With the integration of sophisticated functional safety features, including built-in self-test (BIST), diagnostics, and write protection, the MPQ79531FS-AEC1 supports applications with a high automotive safety integrity level (ASIL) rating.

The MPQ79531FS-AEc1 is available in a QFN-16 (3mmx3mm) package with wettable flanks, and is AEC-Q100 qualified.

Features & Benefits

Precision Monitoring and Recording:
- 2.7V to 5.5V Input Voltage (V_IN) Range
- 3 Voltage Monitor Inputs
- Absolute Over-Voltage (OV) and Under-Voltage (UV) Thresholds for High-Frequency and Low-Frequency Components:
  - 0.2V to 1.475V, 5mV/Step
  - 0.8V to 5.5V, 20mV/Step
- High DC Accuracy across the Entire Temperature Range
- Analog-to-Digital Converter (ADC) for Voltage-Level Readback
- Power Sequence Recording for Power-On, Power-Off, and Sleep Entry/Exit
- Sync Input/Output (I/O) for Multi-Device Sequence Synchronization

Functional Safety:

Built-In Self-Test (BIST)
Interrupt Output Pin (Fault Reporting)
Cyclic Redundancy Check (CRC) Protection on Registers
Write Protection for Critical Registers
Support Systems Up to ASIL-B
ISO 26262 Functional Safety Compliant

Configurability for Vast Flexibility:

I²C Interface with Packet Error Checking (PEC)
One-Time Programmable (OTP) Memory

Additional Features:

Available in a QFN-16 (3mmx3mm) Package with 0.5mm Pitch and Wettable Flanks
Available in AEC-Q100 Grade 1

Active Part Numbers:

MPQ79531FSGQE-xxxx-AEC1-Z MPQ79531FSGQE-xxxx-AEC1-P MPQ79531FSGQE-0000-AEC1-Z MPQ79531FSGQE-0000-AEC1-P

Meaning of P & Z
