MP2733B
Wide Input Range, 4.5A, I2C-Controlled Switching Charger with NVDC Power Path and Controllable RBFET in OTG
Active Part Numbers:
MP2733BGQC-xxxx-Z MP2733BGQC-xxxx-P MP2733BGQC-0000-Z MP2733BGQC-0000-P
Meaning of P & Z
Related Products
EV2733B-QC-00A Wide Input, 4.5A, I2C-Controlled SW Charger with NVDC Power Path and Controllable RBFET in OTG Evaluation Board
The EV2733B-QC-00A is an evaluation board designed to demonstrate the capabilities of the MP2733B, a wide input, 4.5A, highly integrated, switch-mode battery charger IC for single-cell Li-ion or Li-polymer batteries. This device supports narrow-voltage DC (NVDC) architectures with power path management. It is well-suited for portable applications, such as tablets, mobile internet devices, and smartphones.
The MP2733B’s low-impedance power path optimizes efficiency, reduces battery charging time, and extends battery life.
The I2C serial interface allows the user to flexibly control the device by changing charging and system settings.
The EV2733B-QC-00A supports input sources up to 16V, including standard USB host ports and high-voltage wall adapters with fast-charge capability. The EV2733B-QC-00A supports USB On-The-Go (OTG) operation by supplying 5V with 3A.
Communication Interface Device USB to I2C/PMBus, included with product evaluation kit or can be purchased separately.
