mEZD72402A-F

mEZD72402A-F

4.5V - 36V Input, 3.3V Output, 2A, DC/DC Power Supply

Datasheet

Description

The mEZD72402A-F is an open-frame, 4.5-36V input step-down power module with 2A continuous output current and 3.3V output voltage. It provides up to 89% peak efficiency.

Features & Benefits

4.5V to 36V Wide Operating Input
2A Load Current
Hiccup Short-Circuit Protection
Over-/Under-Voltage Protection
Over-Current Protection
Over-Temperature Protection
Open Design Files and BOM

Active Part Numbers:

mEZD72402A-F

Design Resources

Bill Of Materials

Video

mEZ Plug & Play DC/DC Power Modules

Symbol, Footprint & 3D Model

Gerber

Buy direct from MPS

Quantity Price
1

$8.09 /unit

In stock

Arrives 3-4 business days.
Shipping only $5 per order.

Talk to an Engineer or get a Quote

Quality Policy, Certificates & Reliability Reports

All MPS parts are lead-free, halogen-free and adhere to the RoHS directive. See Environmental section for details.
