MPQ79500FS-AEC1

MPQ79500FS-AEC1

MPSafe™ 6-Channel ASIL-D Voltage Monitor, AEC-Q100 Qualified

Datasheet

Description

The MPQ79500FS is a 6-channel voltage monitor. It is engineered for automotive applications that require voltage rails to be monitored for safety, such as advanced driver-assistance systems (ADAS) and autonomous driving platforms.

Each voltage monitor input has configurable over-voltage (OV) and under-voltage (UV) thresholds. Highly accurate high-frequency (HF) and low-frequency (LF) voltage monitoring can detect when the voltage thresholds are reached.

Two of the inputs are differential, remote voltage-sensing input pairs that are well-suited to monitor voltage rails with high current levels. Low-power mode (LPM) can be enabled to achieve extremely low quiescent currents.

The MPQ79500FS can record the order in which voltage rails are sequenced, as well as their associated timestamps. The device also provides a sync I/O function, which allows multiple devices to be connected together to increase the number of voltage rails that can perform these functions. The device is accessible through an I²C interface.

With the integration of sophisticated functional safety features, including built-in self-testing (BIST), diagnostics, and write protection, this device is targeted to support applications with a high automotive safety integrity level up to ASIL-D.

The MPQ79500FS is available in a QFN-16 (3mmx3mm) package with wettable flanks, and is AEC-Q100 Grade 1 qualified.

Features & Benefits

Designed for Automotive Advanced Driver-Assistance System (ADAS) and Autonomous Driving Platforms:
- 2.7V to 5.5V Input Voltage (V_IN) Range
- 6 Voltage Monitor Inputs: 4 Single-Ended, 2 Differential
- Absolute Over-Voltage (OV)/Under-Voltage (UV) Thresholds for High-Frequency and Low-Frequency Components:
  - 0.2V to 1.475V, 5mV/Step
  - 0.8V to 5.5V, 20mV/Step
- High DC Accuracy:
  - >1V, ±0.5%
  - <1V, ±5mV
- Analog-to-Digital Converter (ADC) for Voltage-Level Readback
- Selectable High-Power Mode (HPM) and Low-Power Mode (LPM)
- Power Sequence Recording for Power-On, Power-Off, and Sleep Entry/Exit
- SYNC I/O for Multi-Device Sequence Synchronization
- Write Protection for Critical Registers
Functional Safety:
- Built-In Self-Testing (BIST)
- Interrupt Output Pin (Fault Reporting)
- Cyclic Redundancy Check (CRC) Protection on Registers
- Supports Systems Up to ASIL-D
- ISO 26262 Functional Safety Certified
Flexible Application with I²C Interface:
- I²C Interface with PEC
- One-Time Programmable (OTP) Memory
Additional Features:
- Available in a QFN-16 (3mmx3mm) Package with 0.5mm Pitch and Wettable Flanks
- Available in AEC-Q100 Grade 1

Active Part Numbers:

MPQ79500FSGQE-0000-AEC1-Z MPQ79500FSGQE-0000-AEC1-P

Meaning of P & Z
