MPQ4230

36V, 6A Peak, Buck-Boost Converter with I²C Interface for Automotive Power Delivery, AEC-Q100

プレリリース

Datasheet

概要

The MPQ4230 is a buck-boost converter with four integrated power switches. The device can deliver up to 5A of output current within a certain input-supply range with excellent load and line regulation.

The MPQ4230 is designed for USB power delivery (USB PD) application. It can work well with external USB PD controller through an I²C interface. The I²C interface and MTP (2-time programmable) provide flexibility of configurable features.

Fault condition protections include CC current limiting, output OVP, and thermal shutdown (TSD). The MPQ4230 requires a minimal number of readily available, standard external components. The MPQ4230 is available in a QFN-21 (4mmx5mm) package.

機能と利点

Supports 60W Buck-Boost or 5A Peak I_OUT
Wide 4V to 36V Operating Input Voltage Range
3.6V to 20.5V Output Voltage Range, 10mV resolution
250kHz, 350kHz, and 420kHz Frequency Selectable or SYNC Input
Frequency Spread Spectrum Selectable
Line Drop Compensation
Accurate CC Output Current Limit
I²C Interface and 2-Times Programmable MTP (PMBus Compatible):
- PFM/PWM Mode, Current Limit, Output Voltage, Frequency Spread Spectrum, Line Drop Comp, etc.
- CRC Check for MTP Integrity
Battery Short-to-Ground Protection Driver
Load-Shedding Alert
EN Shutdown Active Discharge
Available in a QFN-21 (4mmx5mm) Package with Wettable Flanks
Available in AEC-Q100 Grade
