- MP6212-3
MP6212-3
NOT RECOMMENDED FOR NEW DESIGNS
3.3V/5V, Single-Channel 1A Current-Limited Power Distribution Switches with different Flag function
MP6212-3 continues to be in production for existing customers. Please consider this alternative for new designs:

MP5075L
MP5075L
5.5V, 1A, Low RDS(ON) Load Switch
Features & Benefits
- Integrated 80mΩ Low RDS(ON) MOSFETs
- Wide VIN Range from 3V to 5.5V
- <5µA Shutdown Current
- Typical 1.4A Current Limit
- Output Discharge Function
- Internal Fixed 450μs Soft-Start Time
- <200ns Short-Circuit Protection Response Time
- Thermal Protection
- Available in a SOT563 (1.6mmx1.6mm) Package
… and many more!
Session textval
Session Titefor popup
Description
The MP6211-3/MP6212-3 single-channel Power Distribution Switch features internal current limiting to prevent damage to host devices due to faulty load conditions. The MP6211-3/MP6212-3 Analog switch has 95mΩ on-resistance and operates from 2.7V to 5.5V input. It is available with guaranteed current limits, making it ideal for load switching applications. The MP6211-3/MP6212-3 has built-in protection for both over current and increased thermal stress. For over current, the device will limit the current by changing to a constant current mode. As the temperature increases as a result of short circuit, the device will shut off. The device will recover once the device temperature reduces to approx 120°C. The FLAG output of MP6211-3/MP6212-3 will report a fail mode (low level) when over current or over temperature is encountered. The FLAG will not change state when the input UVLO is triggered. The MP6211-3/MP6212-3 is available in 8-Pin MSOP with exposed pad, SOIC8 with exposed pad, and TSOT23-5 packages.
-
Show more
Show less
Features & Benefits
- 1A Continuous Current
- Accurate Current Limit
- 2.7V to 5.5V Supply Range
- 90µA Quiescent Current
- 95mΩ MOSFET
- Thermal-Shutdown Protection
- Under-Voltage Lockout
- 8ms FLAG Deglitch Time
- FLAG Won't Change State At Input UVLO Transition
- Reverse Current Blocking
- Active High & Active Low Options
- SOIC8E, MSOP8E

Active Part Numbers:
MP6212DH-3-Z MP6212DH-3-P MP6212DH-3-LF-Z MP6212DH-3-LF-P
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
Meaning of P & Z
