TBMA732-Q-RD-00A

TBMA732-Q-RD-00A

Round Evaluation Board for the MA732

Datasheet

概要

The TBMA732-Q-RD-00A is the round evaluation board for the MA732 MagAlpha magnetic position sensor. This configuration is used for end-of-shaft sensing.

It requires the EVKT-MACOM communication kit and the Macom App Software to evaluate MagAlpha functionality and performance with the set-up, such as noise level, refresh rate, start-up time, and magnetic field dependence.

In addition to this round (RD) evaluation board, there is a long format (LT) version, in which the sensor is mounted on the edge of the board and can therefore be used in both side-shaft and end-of-shaft configurations.

機能と利点

MA732 Round Evaluation Board
Requires the Communication Kit and Software Below

アクティブ部品番号

TBMA732-Q-RD-00A

Evaluation Tools

Macom App Software Evaluation Kit Windows Desktop Application + Drivers for the MagAlpha Communication Kit.

Windows Desktop Application + Drivers for the MagAlpha Communication Kit. Offers a graphical visualization of the angle reading and a quick and easy way to configure the sensor. Requires MagAlpha Communication Kit and a sensor front-end board.

Hardware Requirements

MagAlpha Communication Kit (EVKT-MACOM)

Sensor Board (TBMAxxx-Q-RD, TBMAxxx-Q-LT or EVKTxxx-KNOB)

User Instructions

MACOM Communication Kit User Guide

MagAlpha Communication Kit to Connect to Sensor Test Boards (TMBA) and Rotary Knob Kit, Requires Macom App Software
