5.5A, 600kHz, Synchronous Step-Up Converter with Output Disconnect Evaluation Board

  • 個数 価格
  • 1
    ¥2,716.25 /単位

在庫あり

Arrives 3-4 business days.
Shipping only $5 per order.


評価ボード詳細をご覧ください。
エンジニアにコンタクト、もしくは見積もり入手
すべての購入オプションを見る
代理店価格と詳細はこちらをご参照ください

製品説明

The EV3421-G-00A evaluation board is designed to demonstrate the capability of the MP3421. The MP3421 is a high-efficiency, synchronous, current mode, step-up converter with output disconnect.

The MP3421 can provide inrush current limiting and output short-circuit protection. It can work with an input voltage as low as 1.9V. The integrated P-channel synchronous rectifier improves efficiency and eliminates the need for an external Schottky diode. The PMOS disconnects the output from the input when the part shuts down.

The 600kHz switching frequency allows for small external components, while the internal compensation and soft start minimize the external component count. The MP3421 is available in a QFN-14 (2mmx2mm) package.

製品の特長

  • 1.9V to 5.5V Input Work Range
  • 2.5V to 5.5V Output Range
  • Internal Synchronous Rectifier
  • 600kHz Fixed-Frequency Switching
  • >5.5A Switch Current Limit Capability
  • 43µA Quiescent Current
  • High Efficiency over Full Load Range
  • Internal Soft Start and Compensation
  • True Output Load Disconnect from Input
  • OCP, SCP, OVP, and OTP Protection
  • Available in a Small QFN-14 (2mmx2mm) Package

パラメータ


5.5A, 600kHz High Efficiency, Synchronous Step-Up Converter with Output Disconnect

The MP3421 is a high-efficiency, synchronous, current–mode, step-up converter with true output disconnect.
The MP3421 starts up from low input voltage (as low as 1.9V) while providing in-rush current limiting and output short-circuit protection. The integrated, P-channel synchronous rectifier improves efficiency and eliminates the need for an external Schottky diode; the P-channel disconnects the output load from the input during shutdown.
The MP3421 has 600kHz switching frequency, which accommodates small external components. In addition, its internal compensation and soft-start functions minimize external component count. The MP3421 provides a compact solution for a 5V output, 2.1A load requirement, using a supply voltage as low as 2.8V.
The MP3421 is available in a 14-pin QFN 2mmx2mm package.
