MPQ4468-AEC1
36V, 3.5A, Low-Quiescent Current, Asynchronous Step-Down Converter, AEC-Q100 Qualified
Session textval
Session Titefor popup
Description
The MPQ4468 is a frequency-programmable (350kHz to 2.5MHz), asynchronous, step-down switching regulator with an integrated internal
high-side power MOSFET. It provides up to 3.5A of highly efficient output current with current mode control for fast loop response.
The wide 3.3V to 36V input range accommodates a variety of step-down applications in automotive input environments, and is ideal for batterypowered applications due to its extremely low quiescent current.
The MPQ4468 employs AAM (advanced asynchronous modulation) mode, which helps achieve high efficiency in light-load condition by
scaling down the switching frequency to reduce switching and gate driving losses.
Standard features include soft start (SS), external clock sync, enable (EN) control, and a power good (PG) indicator. High duty cycle and
low dropout mode are provided for automotive cold-crank condition.
Over-current protection (OCP) is employed to prevent the inductor current from running away. Hiccup mode greatly reduces the average
current in short-circuit condition. Thermal shutdown provides reliable, fault-tolerant operation. The MPQ4468 is available in a QFN-16
(3mmx4mm) package.
-
Show more
Show less
Features & Benefits
- Wide 3.3V-to-36V Operating Input Range
- 3.5A Continuous Output Current
- 1μA Low Shutdown Mode Current
- 10μA Sleep Mode Quiescent Current
- Internal 90mΩ High-Side MOSFET
- 350kHz to 2.5MHz Programmable Switching Frequency
- Synchronize to External Clock
- Selectable In-Phase or 180° Out-of-Phase
- Power Good Indicator
- Programmable Soft-Start Time
- 80ns Minimum On Time
- Low Dropout Mode
- Over-Current Protection and Hiccup Mode
- Available in a QFN-16 (3mmx4mm) Package
- AEC-Q100 Grade 1

Active Part Numbers:
MPQ4468GL-AEC1-P MPQ4468GL-AEC1-Z
Part numbers ending in P and Z are the same parts. P and Z only indicates reel size.
Meaning of P & Z
