3.3V/5V, Single-Channel 500mA Current-Limited Power Distribution Switch

Talk to an Engineer or get a Quote

Product Description

The MP62055-3 Power Distribution Switch features internal current limiting to prevent damage to host devices due to faulty load conditions. The MP62055-3 analog switch features 90mΩ on-resistance and operates from 2.7V to 5.5V input. It is available with a guaranteed current limit, making it ideal for load switching applications. The MP62055-3 has built-in protection for both over current and increased thermal stress. For over current, the device will limit the current by changing to a constant current mode.

Product Features

  • 10μs Response Time of Current Limit
  • 500mA Continuous Current
  • Accurate Current Limit
  • 2.7V to 5.5V Supply Range
  • 90μA Quiescent Current
  • 90mΩ MOSFET (SOIC8)
  • 115mΩ MOSFET (TSOT23-5)
  • Thermal-Shutdown Protection
  • Under-Voltage Lockout
  • 8ms FLAG Deglitch Time
  • Reverse Current Blocking
  • TSOT23-5 & SOIC8 Package


  • Output DischargeNo
  • EnableActive High
  • Fault FlagOver Current,Active Low
  • Ilimit (A)0.808
  • Rds(on) (mΩ)115/90
  • GradeCatalog
  • Channels1
  • Iq (typ) (µA)90
  • Iout (max) (A)0.5
  • Vin (max) (V)5.5
  • Vin (min) (V)2.7
  • PackageSOIC-8, TSOT23-5
