MP28368

1.8A, 24V, 1.4MHz Step-Down Converter

Datasheet

Overview
Design Resources
Technical Forum
Quality

Vin (Max) 20V to 29V
MP28368

MP28368

1.8A, 24V, 1.4MHz Step-Down Converter

Datasheet

Description

The MP28368 is a monolithic step-down switch mode converter with a built-in internal power MOSFET. It achieves 1.8A continuous output current over a wide input supply range with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization. Fault condition protection includes cycle?y?ycle current limiting and thermal shutdown. The MP28368 requires a minimum number of readily available standard external components. The MP28368 is available in a 2mm x 2mm QFN8 package.

Features & Benefits

2.5A Peak Output Current
1.8A Continuous Output Current
0.3O Internal Power MOSFET Switch
Stable with Low ESR Output Ceramic Capacitors
0.1? Shutdown Mode
Fixed 1.4MHz Frequency
Thermal Shutdown
Cycle-by-Cycle Over Current Protection
Wide 4.5V to 24V Operating Input Range
Output Adjustable from 0.81V to 15V
Available in a 2x2mm QFN8 Packages

Recommended Inductors

Semi-Shielded Inductor 2.2µH

Low-Profile Molded Inductor 2.2µH

Low-Profile Molded Inductor 2.2µH

Show more

Show more

Inductor Selector Tool

*Based on Nominal Values
