22V, 4A Quad-Channel Half-Bridge / Dual-Channel Full-Bridge Power Amplifier
Learn about our Evaluation Kit
You have a basic account.A myMPS+ account is needed.
Upgrade to myMPS+Product Description
The MP8048 is a configurable dual channel full-bridge or quad channel half-bridge that can be configured as the output stage of a Class-D audio amplifier. Each full-bridge can be driven independently as stereo single ended audio amplifiers or driven complementary in a bridge tied load (BTL) audio amplifier configuration.
The MP8048 features a low current shutdown mode, standby mode, input under voltage protection, current limit, thermal shutdown and fault flag signal output. All channels of drivers interface with standard logic signals.
The MP8048 is available in a 40 lead QFN 6X6 package.
Product Features
- 4A Peak Current Output
- Up to 600KHz Switching Frequency
- Protected Integrated Power 0.2Ω Switches
- 30ns Switch Dead Time
- All Switches Current Limited
- Internal Under Voltage Protection
- Internal Thermal Protection
- 3.4mA Operating Current
- Fault Output Flag
- Single Ended Output Power: 8W/Channel at 22V, 8Ω
- Bridge Tied Load Output Power: 30W/Channel at 22V, 8Ω
Parametrics
- GradeCatalog
- TypeStereo Full-Bridge
- PackageQFN-40 (6x6)
- Isw Limit (A)4
- Total Pout (max) (W)60
- Vin (max) (V)22
- Vin (min) (V)7.5
Evaluation Kit
GET THIS KIT
Kit details
The EV8048DQK-00A is the evaluation board for the MP8048, a configurable dual channel full-bridge or quad channel half-bridge.
The MP8048 features a low current shutdown mode, standby mode, input under voltage protection, current limit, thermal shutdown and fault flag signal output. Each full-bridge can be driven independently as stereo single ended audio amplifiers, or driven complementary in a bridge tied load (BTL) audio amplifier configuration. All channels of drivers interface with standard logic signals.
$75.00 + tax
