5A, 28V, H-Bridge Current Regulator Evaluation Board

Datasheet

Description

The EV6519-Q-00A is an evaluation board for the MP6519, a monolithic, step-down, current-source driver. It operates from a supply voltage of up to 28V, and can deliver current up to 5A.

The four integrated MOSFET H-bridge controls provide a fast dynamic load response and an ultra-high efficiency solution. For ease of use, the output polarity can be controlled by pulling MODE high or low.

Full protection features include open-load, load-short protection, OCP, OTP, and OVP.

Product Evaluated

MP6519

2.5V - 28V, 5A, H-Bridge Current Regulator

Features & Benefits

Wide 2.5V to 28V Input Voltage Range
Up to 5A Output Peak Current
±2% Accuracy at Full-Scale Reference
65mΩ R_DS(ON) for Each MOSFET of H-Bridge
30kHz to 300kHz Programmable Switching Frequency
20kHz to 100kHz PWM Input for Current Regulation
Programmable Full-Scale Current
Selectable Current Polarity Mode
Open-Load Protection, OCP, OTP, and OVP
