EVKT-MPM3593

EVKT-MPM3593

MPM3593 Evaluation Kit: 45V, 3A, High-Efficiency, Digitally Calibrated, Synchronous Step-Down Converter

Datasheet

Description

The MPM3593 is a high-frequency, synchronous, rectified, step-down converter with an I²C control interface and multi-page one-time programmable (OTP) memory. The MPM3593 can achieve up to 3A of continuous output current (I_OUT), with excellent load and line regulation across a wide input supply range.

The MPM3593 is highly customizable and can support a diverse array of applications. Users can configure the MPM3593 via the MPS I²C GUI. However, changes made in I²C mode are not retained once the EVB is powered down.

The EVKT-MPM3593 is a valuable evaluation tool that is well-suited for all types of experience levels, from beginner to expert, and can help users quickly determine whether the MPM3593 is suitable for their target application.

Product Evaluated

Features & Benefits

3.5V to 45V Input Voltage (V_IN)
0.6V to 12V Output Voltage (V_OUT) (Default 5V)
Up to 3A of Continuous Output Current (I_OUT)
Default 500kHz Switching Frequency (f_SW)
Supported Operating Systems: Windows 7 and Later
System Requirements: Minimum 15.6MB Free
EVB Size (6.4cmx6.4cm)

Active Part Numbers:

EVKT-MPM3593

Design Resources

Buy direct from MPS

Standard Pricing

Quantity Price
1

$95.00 /unit

In stock

Arrives 3-4 business days. Shipping only $5 per order.

Quantity

100 Max per Company.
Limited Inventory to support product development.
