EV9184A-L-00A

EV9184A-L-00A

19A, 600kHz, 20V, Wide Input, Synchronous Boost Converter Evaluation Board

Datasheet

Description

The EV9184A-L-00A Evaluation Board is designed to demonstrate the performances of MPS’s MP9184A, which has excellent protection and can provide load with12V/2A power from typical 3.3V input.

The MP9184A is a 600 kHz fixed frequency, high efficiency, wide input range, current mode boost converter with optional internal or external current sensing configuration for high integration and high power application. It features internally a 10mΩ, 24V power switch and a synchronous gate driver for high conversion efficiency. The MP9184A is available in a low profile 22-pin 3mmx4mm QFN package.

This board is configured for 12V application, the maximum output current is determined by current limit, permitted temperature rising and input voltage.

Product Evaluated

19A, 600kHz, 20V Synchronous Boost Converter with Input Disconnect Function

Features & Benefits

3V to 10V Wide Input Range
Integrated 10mΩ Low-side Power FET
SDR Driver for Synchronous Solution
19A Internal Switch Current Limit or External Programmable Input Current Limit
Input Disconnect and Output SCP Protection
External Soft-Start and Compensation for Higher Flexibility
Programmable UVLO and Hysteresis
<1µA Shutdown Current
Thermal Shutdown at 150°C
Available in 3x4mm QFN-22 Package

Active Part Numbers:

EV9184A-L-00A

Buy direct from MPS

Standard Pricing

Quantity Price
1

$25.00 /unit

In stock

Arrives 3-4 business days. Shipping only $5 per order.

Quantity

100 Max per Company.
Limited Inventory to support product development.
