EV8004-QW-00A

EV8004-QW-00A

13W 802.3af PoE-Powered Device Interface with Flyback DC/DC Converter Evaluation Board

Datasheet

Description

The EV8004-QW-00A is an evaluation board for the MP8004, which is an integrated IEEE 802.3af PoE-compliant powered device (PD) power supply solution. It includes a PD interface and an isolated/non-isolated flyback converter.

The PD interface includes detection and classification modes, as well as a 100V output pass device. Inrush current limit is included to slowly charge the input capacitor. The DC/DC converter includes a 150V power switch, and is capable of delivering 13W output power with high efficiency. It has internal soft-start, auto-retry, over current, short circuit, and over-voltage protection. It can also skip cycles during light-load conditions.

The MP8004 is available in a thermally-enhanced QFN-20 (4mmx6mm) package.

Product Evaluated

13W 802.3af PoEPowered Device Interface with Flyback DC/DC Converter

Features & Benefits

Meets IEEE 802.3af Specifications
100V, 1Ω Integrated Pass Switch
420mA DC Input Current Limit
150V, 0.45Ω Integrated Switch for a Power Converter
Cycle-by-Cycle Switching Current Limit
Integrated 100V Start-Up Circuit
Programmable Switching Frequency
Duty Cycle Limiting with Line Feed-Forward
Internal Slope Compensation
OCP, SCP, and OTP Protection
Available in a QFN-20 (4mmx6mm) Package

Active Part Numbers:

EV8004-QW-00A

Buy direct from MPS

Standard Pricing

Quantity Price
1

$25.00 /unit

In stock

Arrives 3-4 business days.
Shipping only $5 per order.

Quantity

100 Max per Company.
Limited Inventory to support product development.
