EV6501A-F-00A

EV6501A-F-00A

2.5A, 35V, Bipolar Stepper Motor Driver Evaluation Board

Datasheet

Description

The EV6501A-F-00A is an evaluation board for the MP6501AGF, a stepper motor driver with a built-in microstepping translator.

The board operates from a 8V to 35V supply voltage range, and can deliver a motor current up to 2.5A. It can drive a bipolar stepper motor
in full- half-, quarter-, and eighth-step modes by setting MS3, MS2, or MS1. The input control signals and reference voltage for the MP6501A are applied through the connector, or generated on the board.

Product Evaluated

Features & Benefits

Wide 8V to 35V Input Voltage Range
Up to 2.5A Configurable Output Current
Full-, Half-, Quarter-, and Eighth-Step Modes
Adjustable Mixed Decay Ratio or Automatic Decay
OCP, OVP, and OTP
Fault Indication Output

Active Part Numbers:

EV6501A-F-00A

Buy direct from MPS

Standard Pricing

Quantity Price
1

$100.00 /unit

In stock

Arrives 3-4 business days. Shipping only $5 per order.

Quantity

100 Max per Company.
Limited Inventory to support product development.

SEE ALL BUYING OPTIONS

View distributor pricing and availability
