EV2312-Q-00A

EV2312-Q-00A

24V, High-Current, Synchronous Step-Down Converter Evaluation Board

Datasheet

Description

The EV2312-Q-00A is an evaluation board for the MP2312, a high-efficiency, monolithic, synchronous step-down converter. The evaluation board can deliver 2.1A continuous load current from a 6V to 24V input, with excellent load and line regulation. Constant-on-time (COT) control mode provides fast transient response and eases loop stabilization.

The evaluation board can be turned on or shut down via a remote on/off input that is referenced to ground. This input is compatible with popular logic devices.

Product Evaluated

2.1A, 24V, 500kHz, Synchronous Step-Down Converters With PG, Light Load Mode and Output Discharge

Features & Benefits

Wide 6V to 24V Operating Input Range
2.1A Continuous Output Current
Low R_DS(ON) Internal Power MOSFETs
Proprietary Switching Loss Reduction Technique
1% Reference Voltage
Internal Soft Start
Output Discharge
500kHz Switching Frequency
OCP, OVP, UVP, and Thermal Shutdown
Available in a QFN (3mmx3mm) Package

Active Part Numbers:

EV2312-Q-00A

Buy direct from MPS

Standard Pricing

Quantity Price
1

$25.00 /unit

In stock

Arrives 3-4 business days.
Shipping only $5 per order.
