10A, 75V, Integrated Half-Bridge Evaluation Board

Datasheet

Description

The EV1930-QN-01A evaluation board is designed to demonstrate the capabilities of the MP1930, an integrated gate driver with one half-bridge consisting of two N-channel MOSFETs.

The EV1930-QN-01A operates from a maximum 75V power input voltage (V_IN) and 18V supply voltage (V_DD). The MP1930 can deliver up to 10A of continuous output current (I_OUT). The driving logic signals are generated by an external controller.

Product Evaluated

Features & Benefits

Recommended 75V Maximum Input Voltage (V_IN)
Simple Logic Interface
Up to 10A of Continuous Output Current (I_OUT)
Transistor-to-Transistor Logic (TTL)-Compatible Input
On-Chip Bootstrap (BST) Diode
Under-Voltage Lockout (UVLO) for Both the High-Side (HS) and Low-Side (LS) Pre-Drivers
Quiescent Current (I_Q) Below 130μA
Available in a QFN-26 (7mmx7mm) Package
