The MP3801 is a high output voltage, DC to AC converter designed for driving Electroluminescent (EL) lamps of up to 5 square inches. The device operates from an input voltage range of 2.5V to 5.5V, making it suitable for 1-cell Li-Ion and 2 or 3-cell alkaline/NiCad/NiMH battery applications. The device uses a single inductor and a minimum number of passive components. The MP3801 converts a low-voltage DC input to a ?5V regulated output voltage that drives the EL lamp. The MP3801 is comprised of two stages: a boost stage and a H-bridge lamp driver stage. The boost stage converts the input voltage up to 95V. The H-bridge stage alternately switches the 95V to each terminal of the EL lamp. The MP3801 has two separate internal oscillators for the boost and H-bridge stages. The frequency of each oscillator is set independently via external resistors. This flexibility allows the EL lamp circuit to be optimized for maximum performance. Also, the IC can be enabled /disabled by connecting these two resistors to VDD/GND. The MP3801 is available in an 8-pin MSOP package.
2.5V to 5.5V DC Input Voltage
190VPP Regulated AC Output Waveform
Single Cell Lithium-Ion Compatible
10nA Shutdown Current
Adjustable EL Lamp Frequency
Adjustable Converter Frequency
Available in MSOP-8
Split Supply Capability
Typical LCD Screen SizesSmall (<10")
Vpp (max) (V)120
Vin (max) (V)5.5
Vin (min) (V)2.5
EL Lamp Driver for Handheld Applications Evaluation Board
The EV3801DH-01A is an evaluation board for the MP3801, a power IC that offers a complete solution for driving an Electroluminescent (EL) lamp of up to 5 square inches from 1-cell Li-Ion or 2 to 3 cell alkaline/NiCad/NiMH battery input.
$25.00 + tax
