The MP2330 is a fully integrated, high-frequency, synchronous, rectified, step-down switch-mode converter with internal power MOSFETs. The device offers a very compact solution that can achieve up to 3A of continuous output current (I_OUT) across a wide input voltage (V_IN) range, with excellent load and line regulation. The MP2330 uses synchronous mode to provide high efficiency across the entire I_OUT load range.

Constant-on-time (COT) control provides very fast transient response, easy loop design, and very tight output regulation. Full protection features include short-circuit protection (SCP), over-current protection (OCP), under-voltage protection (UVP), and thermal shutdown.

The MP2330 requires a minimal number of readily available, standard external components, and is available in a space-saving SOT583 (1.6mmx2.1mm) package.
