MP2305

2A, 23V Synchronous Rectified Step-Down Converter

MP2305

NOT RECOMMENDED FOR NEW DESIGNS

2A, 23V Synchronous Rectified Step-Down Converter

MP2305 continues to be in production for existing customers. Please consider this alternative for new designs:

MP2314SGJ-Z

Active

MP2314SGJ-Z

Active

2A, 24V, 500kHz, High-Efficiency, Synchronous, Step-Down Converter

Features & Benefits

  • Wide 4.5V to 24V Operating Input Range
  • 2A Load Current
  • 140mO/65mO Low RDS(ON) Internal Power MOSFETs
  • Low Quiescent Current
  • High-Efficiency Synchronous Mode Operation
  • Fixed 500kHz Switching Frequency
  • AAM Power Save Mode
  • Internal Soft Start
  • Output Over-Voltage Protection (OVP)
  • Over-Current Protection (OCP) and Hiccup
  • Thermal Shutdown
  • Output Adjustable from 0.8V
  • Available in an TSOT23-8 Package

… and many more!

Active Part Numbers:

MP2305DS-LF-P MP2305DS-LF-Z MP2305DS-LF MP2305XN

Meaning of P & Z Show more
