MP2205A
16V, 2.5A, 1.3MHz Synchronous Step-Down Converter

MP2205A

16V, 2.5A, 1.3MHz Synchronous Step-Down Converter

MP2205A continues to be in production for existing customers. Please consider this alternative for new designs:

MP1477HGTF-Z

Active

MP1477HGTF-Z

Active

17V, 3A, 1.2MHz, High-Efficiency, Synchronous, Step-Down Converter in a SOT563 Package

Features & Benefits

  • Wide 4.2V to 17V Operating Input Range
  • 58mΩ/25mΩ Low RDS(ON) Internal Power MOSFETs
  • 200µA Low I
  • High-Efficiency Synchronous Mode Operation
  • Forced PWM Mode Operation
  • Fast Load Transient Response
  • 1.2MHz Switching Frequency
  • Internal Soft Start (SS)
  • Over-Current Protection (OCP) and Hiccup Mode
  • Thermal Shutdown
  • Output Adjustable from 0.8V
  • Available in a SOT563 (1.6mmх1.6mm) Package

… and many more!

Active Part Numbers:

MP2205ADL-LF MP2205ADL-LF-P MP2205ADL-LF-Z

Meaning of P & Z Show more
