EVQ8616-L-12-00A

High Efficiency, 12A, 6V Synchronous Step-down Converter Evaluation Board

Datasheet

Shopping Cart

Order

Overview
Technical Forum
Quality
Order

EVQ8616-L-12-00A

EVQ8616-L-12-00A

High Efficiency, 12A, 6V Synchronous Step-down Converter Evaluation Board

Datasheet

Description

The EVQ8616-L-12-00A is an evaluation board for the MPQ8616GL-12, a high efficiency monolithic synchronous step-down converter.

The Evaluation Board can deliver 12A continuous load current from a 3V to 6V input with excellent load and line regulation.

Constant-On-Time (COT) control mode provides fast transient response and eases loop stabilization.

The Evaluation Board can be turned on or shut down via a remote ON/OFF input that is reference to ground. This input is compatible with popular logic devices.

Product Evaluated

12A, 6V, CCM, Non-latch OVP and OCP, COT Synchronous Step-down Converter

Features & Benefits

Wide 3V to 6V Operating Input Range
12A Output Current
16m?/8.4m? Internal Power MOSFETs
Proprietary Switching Loss Reduction Technique
Adaptive COT for Ultrafast Transient Response
1% Reference Voltage Over -20 to +85 Junction Temperature Range
Programmable Soft Start Time
Pre-Bias Start up
Programmable Switching Frequency from 300kHz to 1MHz.
Non-Latch OCP, Non-Latch OVP Protection and Thermal Shutdown
Available in a QFN3x4 package
