28V, 5A, H-Bridge Motor Driver Evaluation Board

Description

The EV6619-Q-00A is an evaluation board for the MP6619, an H-Bridge motor driver that operates from a supply voltage up to 28V and delivers a motor current up to 5A.

The MP6619 has cycle-by-cycle current regulation and limiting. It is typically used to drive a brushed DC motor. Full protection features include over-current protection (OCP), over-voltage protection (OVP), overtemperature protection (OTP) and under voltage lockout (UVLO).

Features & Benefits

Wide 5.4V to 28V Input Voltage Range
Up to 5A Peak Output Current
65m? RDS(ON) for Each MOSFET of H-Bridge
100% Duty Cycle Operation of H-Bridge
1μA Shutdown Current
Full Protection Features
IC is Available in a QFN-19 (3mmx3mm) Package
