EV26057DQ-00A

Active

28V, 1A Linear Li-Ion Travel Charger With Trickle Charge and Timer EV Board

  • Quantity Price
  • 1
    $25.00 /unit

In stock

Arrives 3-4 business days.
Shipping only $5 per order.


Learn about our Evaluation Kit
Talk to an Engineer or get a Quote

Product Description

The MP26057 is a linear, high performance single cell Li-Ion or Li-Polymer battery charger with on-chip input polarity reverse protection down to -16V. By integrating high voltage input protection into the charger IC, the MP26057 can tolerate an input surge up to 28V.

The device features constant current (CC) and constant voltage (CV) charging modes with programmable charge currents (200mA to 1A), current blocking and trickle charge. The other features include the programmable battery full threshold, termination and auto-recharge. MP26057 provides charger status indication to drive red and green LEDs (tri-color indication). For guaranteed safe operation, the MP26057 limits the die temperature to a preset value when the device is heated up due to limited PCB space. Other safety features are battery temperature monitoring, and programmable timer to prevent prolonged charging a dead battery.

Product Features

  • Input Surge Up to 28V
  • Adapter or USB Input
  • Programmable Charge Current: 200mA to 1A
  • Proprietary Over-Voltage Protection
  • 0.75% VBATT Accuracy
  • Battery Temperature Monitoring
  • AC Adapter Power Good Indicator
  • Charge Status Indicator
  • Battery full terminated control
  • Time off control
  • Fully assembled and Tested

Parametrics


28V, 1A Linear Li-lon Travel Charger with Trickle Charge and Timer

The MP26057 is a linear, high performance single cell Li-Ion or Li-Polymer battery charger with on-chip input polarity reverse protection down to -16V. By integrating high voltage input protection into the charger IC, the MP26057 can tolerate an input surge up to 28V. The device features constant current (CC) and constant voltage (CV) charging modes with programmable charge currents (200mA to 1A), current blocking and trickle charge. The other features include the programmable battery full threshold, termination and auto-recharge. MP26057 provides charger status indication to drive red and green LEDs (tri-color indication). For guaranteed safe operation, the MP26057 limits the die temperature to a preset value when the device is heated up due to limited PCB space. Other safety features are battery temperature monitoring, and programmable timer to prevent prolonged charging a dead battery. MP26057 is available in a 10-pin 3mm x 3mm DFN package.

Quality Policy, Certificates & Reliability Reports
All MPS parts are lead-free, halogen-free and adhere to the RoHS directive. See Environmental section for details.
