The EV2316-D-00A is used for demonstrating the performance of the MP2316, a fully integrated, high-efficiency, synchronous, step-down, switch mode converter with a feathered 40µA quiescent current. The MP2316 provides up to 3A of continuous output current over a wide input supply range with constant-on-time control for fast loop response.

High power efficiency over a wide load range is achieved by scaling down the switching frequency in light-load conditions to reduce switching-related loss viaconstant-on-time control. Short circuit protection (SCP) and thermal shutdown provide reliable, fault-tolerant operation.

The MP2316 is available in a 14-pin QFN (2mmx3mm) package.
