The EV2013B-33-J_Q_G-00A is an evaluation board for the MP2013B-33, MPQ2013B-33, and MPQ2013B-33-AEC1, a low linear regulator that supplies power to systems with high-voltage batteries.
The MP2013B-33/MPQ2013B-33/MPQ2013B-33-AEC1 include a wide 4.3V to 40V input range, low-dropout voltage and low quiescent supply current. The low quiescent current and low-dropout voltage allows operations at extremely low power levels. Therefore, the MP2013B-33/MPQ2013B-33/MPQ2013B-33-AEC1 are ideal for the low-power microcontrollers and battery-powered equipment.
The EV2013B-33-J_Q_G-00A is a fully assembled and tested evaluation board. It generates a 3.3V output voltage at load currents up to 150mA from a 4.3V to 40V input range.
