EV1400-C-01A

The EV1400-C-01A demonstrates MPS’s MP1400, a monolithic negative DCDC power converter with built-in internal power MOSFET. It offers a very compact solution to achieve up to 600mA continuous output current depending on input-voltage to output-voltage ratio. The output voltage can be regulated from -0.9V to    -6V.

The 1500 kHz switching frequency allows for smaller external components producing a compact solution for a wide range of load currents.

Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown.  The MP1400 is available in a 0.8mm x 1.6mm 8-ball CSP package.
