EV06W0503A-2-Y-00B

EV06W0503A-2-Y-00B

0.6W, Semi-Regulated, 1.5kV_DC Isolated DC/DC Converter Evaluation Board

Description

The EV06W0503A-2-Y-00B is an evaluation board designed to demonstrate the capabilities of the MID06W0503A-2, a semi-regulated, isolated DC/DC converter. The MID06W0503A-2 supports a 1.5kV_DC isolation voltage.

The MID06W0503A-2 integrates a power MOSFET, transformer, and feedback circuit all in one chip. The DC/DC converter provides a compact solution with reliable operation compared to traditional isolated power modules.

It is recommended to read the datasheet for the MID06W0503A prior to making any changes to the EV06W0503A-2-Y-00B.

Product Evaluated

MID06W0503AGY-2S

0.6W, Semi-Regulated, 1.5kV_DC Isolated DC/DC Converter

Features & Benefits

4.5V to 5.5V Operating Input Voltage (V_IN) Range
3kV_DC Isolation Voltage
Up to 0.6W Output Power (P_OUT)
38% Max Efficiency at Full Loads
0.5% Load Regulation
1% Line Regulation
Excellent Transient Response
Continuous Short-Circuit Protection (SCP) with Hiccup Mode
Over-Temperature Protection (OTP)
Meets CISPR32 Class B Emissions
CB Certification According to IEC62368-1 (In Process)
-40°C to +125°C Operating Temperature Range
Available in an SOICW-16 Package
