0.25W, Regulated, 1.5kV_DC Isolated DC/DC Converter Evaluation Board

Description

The EV02W0303A-2-Y-00B is an evaluation board designed to demonstrate the capabilities of the MID02W0303A-2, a regulated, isolated DC/DC converter. The MID02W0303A-2 supports a 1.5kV_DC isolation voltage.

The device integrates a power MOSFET, transformer, and feedback circuit in one chip. The DC/DC converter is a compact solution with reliable operation compared to traditional isolated power modules.

It is recommended to read the datasheet for the MID02W0303A-2 prior to making any changes to the EV02W0303A-2-Y-00B.

Product Evaluated

MID02W0303AGY-2R

0.25W, Regulated, 1.5kV_DC Isolated DC/DC Converter

Features & Benefits

3V to 3.6V Operating Input Voltage (V_IN) Range
1.5kV_DC Isolation Voltage
Up to 0.25W Output Power (P_OUT)
52% Max Efficiency with Full Loads
0.2% Load Regulation
0.1% Line Regulation
Excellent Transient Response
Short-Circuit Protection (SCP) with Hiccup Mode
Over-Temperature Protection (OTP)
Meets CISPR32 Class B Emissions
-40°C to +125° Operating Temperature Range
Available in an SOICW-16 Package
