MP5403

NOT RECOMMENDED FOR NEW DESIGNS

6V Mini PMIC with High Efficiency Dual 2.5A/3.5A Buck, One Load Switch and Input Power Supervisory

ALTERNATIVE PART

NRFND Datasheet

MP5403 continues to be in production for existing customers. Please consider this alternative for new designs:

MP5479GRM

2.7V to 5.5V PMIC with 4 Buck Converters (2A/2.5A/4.5A/4.5A), 5 LDOs, and Configurable System Settings via the I²C and MTP

Features & Benefits

High-Efficiency Step-Down Converters:
- Buck 1: 4.5A DC/DC Converter
- Buck 2: 2.5A DC/DC Converter
- Buck 3: 4.5A DC/DC Converter
- Buck 4: 2A DC/DC Converter
- Buck 1 and Buck 3 Can Work in Parallel
- Buck 2 and Buck 4 Can Work in Parallel
- 2.7V to 5.5V Operating Input Voltage (V_IN) Range
- Buck 1, Buck 2, and Buck 3 Optional V_OUT Range: 0.4V to 3.58V/12.5mV Step or 0.4V to 2.2V/7.4mV Step
- Buck 4 V_OUT Range: 0.4V to 3.58V/12.5mV Step
- Adjustable Switching Frequency (f_SW)
- Adjustable Soft-Start Time (t_SS)
- Adjustable Phase Delay
- Configurable PWM Mode, Auto-PFM Mode, and Forced PWM Mode
- Output Over-Current Protection (OCP)
- Output Over-Voltage Protection (OVP)
- One Dedicated RTC LDO
- Four Low-Noise LDOs
- Two Separate Input Power Supplies
- 50mV Dropout at 300mA Load
System:
- I²C Bus and User-Configurable MTP
- Two-Time Programmable MTP with MP5479GRM-0000
- Power-On/Off Control
- Multi-Function LDO2/EN1 Pin (EN1 Input Logic Level ≤ 3.3V)
- Power-On Reset Output
- Flexible Power-On/Off Sequence via the MTP (0.5ms, 2ms, 8ms, or 16ms Selectable Time Slot)
- Flexible DC/DC, LDO On/Off via the MTP
- Available in a QFN-26 (3.5mmx4.5mm) Package
Optimized Performance with MPS Inductor MPL-AL6050 Series

… and many more!

概要

The MP5403 is a monolithic power management unit containing two high-efficiency, step-down, switching converters and a load switch. The two regulators supply current up to 3.5A and 2.5A separately, and the load switch supplies up to 3A of load current with an extremely low RDS(ON). With an input range of up to 6V, the MP5403 is ideal for powering ASIC and SOC for solid-state drives and other compact power systems.
The peak-current-mode control scheme with pulse-skip-mode operation provides the two switchers with fast transient response, high light-load efficiency, and minimum capacitance by using an interleaving PWM clock between the two switchers. The 3A load switch with a low 20mΩ on resistance provides flexible system configuration.
A full set of enable control pins and power good open-drain indicators allow for easy implementation of the start-up and shutdown sequences.
Full protection features include over-current protection (OCP) and thermal shutdown.
The MP5403 requires a minimal number of readily available, standard, external components and is available in a small UTQFN-20 (2.5mmx3mm) package.

機能と利点

Low Iq: 85µA for Two Switchers Total
Two Buck Converters
o 3.5A with 55mΩ/20mΩ RDS(ON)
o 2.5A with 60mΩ/22mΩ RDS(ON)
o 1.5MHz Switching Frequency
o 180° Interleaving Operation
o 100% Duty Cycle
o Load Switch Mode by Pulling FB Low
o Latch-Off Short-Circuit Protection (SCP)
o Parallel Capability by Connecting SW Nodes Together
o Internal Soft Start and Output Discharge
o Optimized Light-Load Efficiency
Available Fixed Output Options via Package Trim:
Ch1: 0.9V, 1.1V, 2.5V, 2.85V
Ch2: 0.9V, 1.2V, 1.8V, 2.5V
One Load Switch
o 3A with 20mΩ RDS(ON)
o Soft Start and Output Discharge
o Over-Current Protection (OCP)
EN and Power Good for Power Sequencing
Input Power Failure Indicator (PFL) with Adjustable Threshold and Delay
Thermal Shutdown
Available in Ultra-Thin UTQFN-20 (2.5mmx3mm) Package

アクティブ部品番号

MP5403GQBU-P MP5403GQBU-Z

P＆Zの意味

Evaluation Tools

EV5403-QB-02A Evaluation Kit High Efficiency Dual Buck and One Load Switch Power Management Unit EV Board

The EV5403-QB-02A Evaluation Board is designed to demonstrate the capabilities of MPS’ MP5403. The MP5403 is a monolithic power management unit containing two high efficiency step-down switching converters and a load switch. The two regulators supply current up to 3.5A and 2.5A separately and the load switch supplies up to 3A load current with extremely low R_ON resistance. With the input range up to 6V, the MP5403 is ideal for powering ASIC and SOC for Solid-State Drive or other compact power systems.

The MP5403 requires a minimum number of readily available standard external components and is available in a small QFN20 (2.5mmx3mm) package.
