Stability Analysis in Time Domain

Register to access the on-demand webinar, which was hosted on Tuesday, June 24th this year, and learn how to ensure stable automotive DC-DC converters through time-based analysis.

Modern automotive systems—like infotainment and ADAS—demand tight voltage regulation despite dynamic pulsating loads. To meet this, next-gen DC-DC converters need fast loop responses. Load transient testing offers a quick, effective method to evaluate converter performance, including regulation speed and loop stability. By applying fast load changes and observing output with an oscilloscope, engineers can assess stability without expensive frequency response analyzers.

The following topics will be covered in this webinar:

Measure the loop stability in time domain
Estimate the cross-over frequency and phase margin
Understand influence of output capacitor and tune feed-forward capacitor for loop stability
