NOT RECOMMENDED FOR NEW DESIGNS
MP6905 continues to be in production for existing customers. Please consider this alternative for new designs:
Fast Turn-Off Intelligent Rectifier with Very Low Voltage Forward Regulation
Features & Benefits
- Works with 12V Standard and 5V Logic Level FETS
- Fast Turn-Off Total Delay of 25ns
- 4.2V~35V Wide VDD Operating Range
- 30mV VDS Regulation Function
- 150µA Quiescent Current in Light-Load Mode
- Supports DCM and Quasi-Resonant Operation
- SYNC Interface for CCM Operation
- Supports High-Side and Low-Side Rectification
- Power Savings of up to 1.5W in a Typical Notebook Adapter
- SOIC-8 and TSOT23-6 Packages
… and many more!
Active Part Numbers:
Meaning of P & Z
